Yanmar Generator

Click to enlarge

Diesel Generator

PowerRange:6KVA-74KVA
Related Presentations
Yanmar Series Generator Set

Established in 1912, Japan's Yanmar Co., Ltd. has the most advanced engine technology and is recognized as the world's recognized diesel engine brand. It is particularly proud of its products and services. Not only high-quality products and quality services have recognized market competitive advantages, Yanmar engines are also known for their green environmental protection and commitment to the development of the most advanced fuel-saving technologies.
1. Powered by Yanmar Diesel engine
2. Equipped with famous Brushless alternator – Optional Stamford, Leroy-Somer, Marathon, Mecc alte, Kingway,
3. Equipped with optional controller system , Deep sea, ComAp , Smartgen
advanced generator set control system,  ATS system, remote control system, parallel operation system.
4. Radiator 40C max, fans are driven by belt, with safety guard

Manufacturing Standard
ISO8528,GB/T2820,ISO9001,ISO14001,CE


Yanmar 50HZ
Genset Model Prime / Standby
power
Engine
Model
Consumption
(L/h)
Cylinder Displacement
(L)
Genset
 Dimension
(mm)
Weight
(kg)
KVA KW
KGA6 6/6.8 5/5.5 3TNM68 2 3L 0.78 1150x600x1150 310
KGA9 9/10 7.2/8 3TNV76 2.8 3L 1.116 1480x750x1270 425
KGA10 10/11 8/8.8 3TNV82A 3.4 3L 1.331 1480x750x1270 430
KGA12 12.5/13.8 10/11 3TNV88 4 3L 1.642 1480x750x1270 450
KGA14 14.5/16 11.6/12.8 3TNV84T 5 3L 1.496 1480x750x1270 485
KGA17 17.5/19.2 14/15.4 4TNV88 5.3 4L 2.19 1630x750x1270 495
KGA20 20/22 16/17.6 4TNV84T 6.2 4L 1.995 1630x750x1270 505
KGA30 30/33 24/26.4 4TNV98 9.2 4L 3.319 1830x750x1330 660
KGA35 35/37.5 28/30 4TNV98 9.2 4L 3.319 1830x750x1330 660
KGA42 42.5/46.7 34/37.4 4TNV98T 11 4L 3.319 1830x750x1330 605
KGA50 50/55 40/44 4TNV106 16.4 4L 4.412 1930x750x1410 605
KGA60 60/66 48/52.8 4TNV106T 16.4 4L 4.412 1930x750x1410 605

Yanmar 60HZ
Genset Model Prime / Standby
 power
Engine
Model
Consumption
(L/h)
Cylinder Displacement
 (L)
Genset
 Dimension
(mm)
Weight
(kg)
KVA KW
KGAS12 12/13.2 7.2/8 3TNV76 3.3 3L 1.116 1460x730x1170 510
KGAS15 15/16.5 9.6/10.6 3TNV82V 4 3L 1.331 1460x730x1170 520
KGAS18 18/20 12/13.2 3TNV88 4.7 3L 1.642 1460x730x1170 560
KGAS24 24/26.5 16.4/18 4TNV88 6.3 4L 2.19 1630x730x1170 645
KGAS37 37/40.4 20.4/22.8 4TNV84T 7.8 4L 1.995 1630x730x1170 660
KGAS43 43/47.5 27/30 4TNV98 11 4L 3.319 1910x730x1170 790
KGAS24 24/26.5 39.2/45.2 4TNV98T 13.1 4L 3.319 1910x730x1170 840
KGAS37 37/40.4 46.4/51.2 4TNV106 17.8 4L 4.412 1980x730x1550 1000
KGAS43 43/47.5 53.6/59.2 4TNV106T 18.8 4L 4.412 1980x730x1550 1000
