Volvo Generator
Diesel Generator
PowerRange:80KVA-635KVA
Related Presentations
Volvo Series Generator Set
Volvo Corporation is the largest industrial enterprise in Sweden, Owing 120-year development history, this corporation is one of richly historied engine manufacturers in the world, so far, its engine output has achieved more than one million sets, meanwhile, Volvo is the unique manufacturer specialized in producing L4 and L6 diesel engine, so Volvo is the most perfect selection of generating set.
1. Powered by Volvo Diesel engine
2. Equipped with famous Brushless alternator – Optional Stamford, Leroy-Somer, Marathon, Mecc alte, Kingway,
3. Equipped with optional controller system , Deep sea, ComAp , Smartgen
advanced generator set control system, ATS system, remote control system, parallel operation system.
4. Radiator 40C max, fans are driven by belt, with safety guard.
Manufacturing Standard
ISO8528,GB/T2820,ISO9001,ISO14001,CE
Volvo 50HZ
Volvo 60HZ
Volvo Corporation is the largest industrial enterprise in Sweden, Owing 120-year development history, this corporation is one of richly historied engine manufacturers in the world, so far, its engine output has achieved more than one million sets, meanwhile, Volvo is the unique manufacturer specialized in producing L4 and L6 diesel engine, so Volvo is the most perfect selection of generating set.
1. Powered by Volvo Diesel engine
2. Equipped with famous Brushless alternator – Optional Stamford, Leroy-Somer, Marathon, Mecc alte, Kingway,
3. Equipped with optional controller system , Deep sea, ComAp , Smartgen
advanced generator set control system, ATS system, remote control system, parallel operation system.
4. Radiator 40C max, fans are driven by belt, with safety guard.
Manufacturing Standard
ISO8528,GB/T2820,ISO9001,ISO14001,CE
Volvo 50HZ
| Genset Model |
Prime / Standby power |
Engine model |
Fuel consumption (L/h) |
Cylinder |
Displacement (L) |
Genset Dimension (mm) |
Weight (kg) |
|
| KVA | KW | |||||||
| KGV80 | 80/90 | 64/72 | TD520GE | 19.3 | 4L | 4.76 | 2020x850x1565 | 996 |
| KGV100 | 100/110 | 80/88 | TAD531GE | 22.8 | 4L | 4.76 | 2020x850x1612 | 1023 |
| KGV115 | 115/126 | 92/101 | TAD532GE | 28.6 | 4L | 4.78 | 2350x880x1612 | 1392 |
| KGV125 | 125/138 | 100/110 | TAD532GE | 28.6 | 4L | 4.76 | 2350x880x1612 | 1442 |
| KGV150 | 150/165 | 120/132 | TAD731GE | 32.9 | 6L | 7.15 | 2350x880x1612 | 1442 |
| KGV180 | 180/200 | 144/160 | TAD732GE | 40.3 | 6L | 7.15 | 2550x995x1780 | 1850 |
| KGV200 | 200/220 | 160/176 | TAD733GE | 43.6 | 6L | 7.15 | 2550x995x1780 | 1850 |
| KGV250 | 250/275 | 200/220 | TAD734GE | 51.8 | 6L | 9.36 | 2800x1015x1780 | 2224 |
| KGV312 | 312/343 | 250/275 | TAD941GE | 66.1 | 6L | 9.36 | 2910x1107x1800 | 2446 |
| KGV375 | 375/412 | 300/330 | TAD1343GE | 73.6 | 6L | 12.13 | 3100x1114x1830 | 3400 |
| KGV400 | 400/450 | 320/360 | TAD1344GE | 80.2 | 6L | 12.13 | 3130x1114x1887 | 3400 |
| KGV450 | 450/500 | 360/400 | TAD1345GE | 88.5 | 6L | 16.12 | 3130x1114x1887 | 3678 |
| KGV500 | 500/550 | 400/440 | TAD1641GE | 99.9 | 6L | 16.12 | 3300x1160x2030 | 3678 |
| KGV570 | 570/625 | 456/500 | TAD1642GE | 113.7 | 6L | 16.12 | 3300x1160x2030 | 3818 |
| KGV635 | 635/700 | 506/560 | TAD1643GE | 124.2 | 6L | 16.12 | 3450x1400x2080 | 3918 |
Volvo 60HZ
| Genset Model |
Prime / Standby power |
Engine model |
Fuel consumption (L/h) |
Cylinder |
Displacement (L) |
Genset Dimension (mm) |
Weight (kg) |
|
| KVA | KW | |||||||
| KGVS88 | 88/96 | 70/77 | TD520GE | 19.3 | 4L | 4.76 | 2020x850x1565 | 996 |
| KGVS105 | 105/115 | 84/92 | TAD531GE | 22.8 | 4L | 4.76 | 2020x850x1612 | 1023 |
| KGVS132 | 132/146 | 106/117 | TAD532GE | 28.6 | 4L | 4.78 | 2350x880x1612 | 1392 |
| KGVS161 | 161/177 | 129/142 | TAD731GE | 32.9 | 6L | 7.15 | 2350x880x1612 | 1442 |
| KGVS206 | 206/225 | 165/180 | TAD732GE | 40.3 | 6L | 7.15 | 2550x995x1780 | 1850 |
| KGVS225 | 225/248 | 180/198 | TAD733GE | 43.6 | 6L | 7.15 | 2550x995x1780 | 1850 |
| KGVS250 | 250/275 | 200/220 | TAD734GE | 51.8 | 6L | 9.36 | 2800x1015x1780 | 2224 |
| KGVS343 | 343/378 | 275/303 | TAD941GE | 66.1 | 6L | 9.36 | 2910x1107x1800 | 2446 |
| KGVS410 | 410/451 | 328/361 | TAD1343GE | 73.6 | 6L | 12.13 | 3100x1114x1830 | 3400 |
| KGVS456 | 456/501 | 365/401 | TAD1344GE | 80.2 | 6L | 12.13 | 3130x1114x1887 | 3400 |
| KGVS506 | 506/562 | 405/450 | TAD1640GE | 99.9 | 6L | 16.12 | 3300x1160x2030 | 3678 |
| KGVS570 | 570/627 | 456/502 | TAD1641GE | 99.9 | 6L | 16.12 | 3300x1160x2030 | 3678 |
| KGVS625 | 625/687 | 500/550 | TAD1642GE | 113.7 | 6L | 16.12 | 3300x1160x2030 | 3818 |
| KGVS687 | 687/756 | 550/605 | TAD1643GE | 124.2 | 6L | 16.12 | 3450x1400x2080 | 3918 |
